DF SERIES FLOOR SCALE PLATFORMS
Versatile, low cost floor scale platform
| DF1500BS | DF1500BR | DF1500BL | DF1500BLX | DF1500BX | |
| Maximum Capacity | 1,500 kg | 1,500 kg | 1,500 kg | 1,500 kg | 1,500 kg |
| Readability | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg |
| Readability (Certified) | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg |
| Item Number: | 83032905 | 83032906 | 83032907 | 83033738 | 83032909 |
OVERVIEW
| Versatile, low cost floor and pit platform with and without T32M indicator |
Applications N/A |
|
Display N/A |
|
|
Operation N/A
|
|
|
Communication N/A |
|
|
Construction Metal indicator, black painted steel platform, raised embossed treads, fixed top plate 5mm thick, 4 x H8C IP67 OIML R60 alloy steel load cells, IP65 stainless steel junction box |
|
|
Design Features Corresponding ramps and pit mounting options |
SPECIFICATIONS
| DF1500BS | DF1500BR | DF1500BL | DF1500BLX | DF1500BX | |
| Maximum Capacity | 1,500 kg | 1,500 kg | 1,500 kg | 1,500 kg | 1,500 kg |
| Readability | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg |
| Readability (Certified) | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg | 0.5 kg |
| Platform Size | 800 mm x 800 mm | 1,000 mm x 1,000 mm | 1,200 mm x 1,200 mm | 1,200 mm x 1,500 mm | 1,500 mm x 1,500 mm |
| Dimensions | 800 mm x 110 mm x 800 mm (LxHxW) | 1,000 mm x 110 mm x 1,000 mm (LxHxW) | 1,200 mm x 110 mm x 1,200 mm (LxHxW) | 1,200 mm x 110 mm x 1,500 mm (LxHxW) | 1,500 mm x 110 mm x 1,500 mm (LxHxW) |
| Legal for Trade | EC Type Approvable | ||||
| Net Weight | 72 kg | 90 kg | 122 kg | 209 kg | 249 kg |
| Platform Construction | Painted Steel Diamond Plate | ||||
| Protection Rating | IP 65 | ||||
| Working Environment | 14°F – 104°F, 85%RH, non-condensing (-10°C – 40°C, 85%RH, non-condensing) | ||||
ACCESSORIES
|
Item Number 30047153 Description Column Kit, Painted, Floor Scale |
|||||
|
Item Number 30047154 Description Column Kit, SST, Floor Scale |
|||||
|
Item Number 72225239 Description Foot Plate, Set(2), Painted, DF-B |
|||||
|
Item Number 83033708 Description Pit Frame, 800x800mm, Painted, DF-B |
Item Number 83033709 Description Pit Frame, 1000x1000mm, Painted, DF-B |
Item Number 83033710 Description Pit Frame, 1200x1200mm, Painted, DF-B |
Item Number 83033714 Description Pit Frame, 1200x1500mm, Painted, DF-B |
Item Number 83033711 Description Pit Frame, 1500x1500mm, Painted, DF-B |
|
|
Item Number 80252722 Description Ramp DF-B CS 0.8 x 0.75m |
Item Number 80252723 Description Ramp DF-B CS 1 x 0.75m |
Item Number 80252724 Description Ramp DF-B CS 1.2 x 0.75m |
Item Number 80252724 Description Ramp DF-B CS 1.2 x 0.75m |
Item Number 80252725 Description Ramp DF-B CS 1.5 x 0.75m |
|
