Fast, Durable, and Reliable
Ensures longevity in wet environments, reduces maintenance work and downtime, supports fast weighing, and improves efficiency
Easy to clean
The load cell, PCB, and other moisture-sensitive components can be easily removed, making cleaning more efficient
Intuitive Power Supply
Long battery operating time and intuitive three-color indicators for battery volume are helpful in reducing downtime
| Type | BPA121-1211 | BPA121-1221 | BPA121-2211 | BPA121-2221 | BPA121-3211 | BPA121-3221 | BPA121-4211 | BPA121-4221 | BPA121-5211 | BPA121-5221 |
| Material No | 30359343 | 30359344 | 30359345 | 30359346 | 30359347 | 30359348 | 30359349 | 30359350 | 30359351 | 30359352 |
Specifications - Portable Scale BPA121
| BPA121-1211 | BPA121-1221 | BPA121-2211 | BPA121-2221 | BPA121-3211 | BPA121-3221 | BPA121-4211 | BPA121-4221 | BPA121-5211 | BPA121-5221 | |
| Maximum Capacity | 0.75 kg/1.5 kg | 0.75 kg/1.5 kg | 1.5 kg/3 kg | 1.5 kg/3 kg | 3 kg/7.5 kg | 3 kg/7.5 kg | 7.5 kg/15 kg | 7.5 kg/15 kg | 15 kg/30 kg | 15 kg/30 kg |
| Readability | 0.5 g 1 g |
0.5 g 1 g |
1 g 2 g |
1 g 2 g |
2 g 5 g |
2 g 5 g |
5 g 10 g |
5 g 10 g |
10 g 20 g |
10 g 20 g |
| Platform Size (LxHxW) | 300 mm x 133 mm x 230 mm | |||||||||
| Weighing Pan Dimensions (HxWxD) | 182 mm x 226 mm x 182 mm | |||||||||
| Material | Plasitc | |||||||||
| Protection Rating | IP69k IP68 |
|||||||||
| Dimensions (LxHxW) | 300 mm x 133 mm x 230 mm | |||||||||
| Hazardous Approval | No | |||||||||
| Housing | Plastic | |||||||||
| Display | 7-Segment LED | |||||||||
| Repeatability, typical | 0.5 g | 0.5 g | 1 g | 1 g | 2 g | 2 g | 5 g | 5 g | 10 g | 10 g |
| Application Software | Simple weighing | |||||||||
| Repeatability (sd) | 0.5 g | 0.5 g | 1 g | 1 g | 2 g | 2 g | 5 g | 5 g | 10 g | 10 g |
| Applications | Simple Weighing | |||||||||
| Environment | Wet & Harsh Wet (≥IP66) | |||||||||
| Hazardous Area | Non-hazardous area | |||||||||
| Scale Interface | Analog | |||||||||
| Key Pad | Basic function keypad | |||||||||
| Voltage | Lead Acid battery DC Version |
|||||||||
| Hygienic Design | No | |||||||||
| Platform Type | Compact Scale | |||||||||
