European standard-Rack Battery Packs
Basic Specifications
| Power supply model | LF-HPS-51.2V100Ah | LF-HPS-51.2V200Ah |
| Nominal voltage | 51.2V | |
| Nominal capacity | 100Ah/5.12KWh | 200Ah/10.24KWh |
| Charging protection voltage | 56.8V | |
| Discharge protection voltage | 46.4V | |
| Recommended charging current | ≤50A | |
| Maximum charging current | ≤95A | |
| Recommended discharge current | ≤50A | |
| Maximum discharge current | ≤105A | |
| Battery cycle life | ≥6000（25°C±2°C，0.5C charge-discharge，DOD≥80%） | |
| Charging temperature | 5~55℃ | |
| Operating temperature | -20~60℃ | |
| Battery weight | ≈43.5Kg | ≈84Kg |
| Battery size | 473*482*133mm (Adjustable） |
759*553*146mm (Adjustable） |
| Certification | CE、CB、TUV Mark、MSDS、UN38.8 | |
| Communication mode | RS485/RS232/CAN | |
| Adaptable inverter (can customized) |
485：PYLONTECH、TOPBAND、GROWATT、LUXPOWER、CPSYPOWER、SRNE、Felicity solar、ANC、 Shark TopSu CAN：PYLONTECH、Deye、TOPBAND、GROWATT、LUXPOWER、GOODWE、SOFAR、INVT、 MEGAREVO、GINLONG、AFORE、SOROUPS、CFAT、BEITT、MUST、SMA、SACOLAR、TBB |
|
| *Can be customized according to the needs, the final interpretation of this product is owned by the company, subject to change without prior notice |
||
Product Advantages
• Intelligent Battery Management System (BMS), Intelligent Current Blocker, Quadruple Safety
Protection: Voltage Protection, Temperature Protection, and Current Dual Protection；IP54
• Built in fire protection module, 15S fast flame retardant
• Small size, light weight, long service life, and high temperature resistance；Supports well
connection, up to 16 units can be connected in parallel
Applications
Electricity at home, shopping malls, supermarkets, hotels and other
public places
