RANGER™ 2000 COUNT
Effective Counting Scales to Ensure Accurate Results
| RC21P1502 | RC21P3 | RC21P6 | RC21P15 | RC21P30 | |
| Maximum Capacity | 3 lb (1.5 kg) | 6 lb (3 kg) | 15 lb (6 kg) | 30 lb (15 kg) | 60 lb (30 kg) |
| Readability | 0.0001 lb (0.05 g) | 0.0002 lb (0.1 g) | 0.0005 lb (0.2 g) | 0.001 lb (0.5 g) | 0.002 lb (1 g) |
| Platform Size | 8.9 in x 11.8 in (225 mm x 300 mm) | 8.9 in x 11.8 in (225 mm x 300 mm) | 8.9 in x 11.8 in (225 mm x 300 mm) | 8.9 in x 11.8 in (225 mm x 300 mm) | 8.9 in x 11.8 in (225 mm x 300 mm) |
| Item Number: | 30031909 | 30031910 | 30031911 | 30031912 | 30031913 |
OVERVIEW
| The Ranger Count 2000 has all of the capabilities to produce precise results rapidly for a variety of applications. With weighing, parts counting, check counting, and accumulation functions, Ranger Count 2000 is the ideal scale to meet many industrial counting needs. Portable and equipped with a rechargeable battery, this scale is beneficial in every corner of the factory and is equipped with functions and features that elevate the Ranger Count 2000 to a class of its own. |
Applications Weighing, Parts Counting with Auto Optimization, Checkweighing, Accumulation |
|
Display 3 window backlit liquid crystal display (LCD), 3 color checkweighing LEDs |
|
|
Operation AC power (included) or rechargeable battery (included) |
|
|
Communication Easy Access RS232 communication port (included) |
|
|
Construction ABS Housing, ABS platform with stainless steel inset, transportation handle, numeric keypad, menu lock switch, up front level indicator |
|
|
Design Features 30 item library, 210 hours of battery life, 3 LED checkweighing lights with selectable operation and audible signal settings, auto tare, selectable environmental and auto-print settings, auto shut-off, auto tare |
SPECIFICATIONS
| RC21P1502 | RC21P3 | RC21P6 | RC21P15 | RC21P30 | |
| Maximum Capacity | 3 lb (1.5 kg) | 6 lb (3 kg) | 15 lb (6 kg) | 30 lb (15 kg) | 60 lb (30 kg) |
| Readability | 0.0001 lb (0.05 g) | 0.0002 lb (0.1 g) | 0.0005 lb (0.2 g) | 0.001 lb (0.5 g) | 0.002 lb (1 g) |
| Platform Size | 8.9 in x 11.8 in (225 mm x 300 mm) | ||||
| Battery Life | 210 Hours with Rechargeable Battery | ||||
| Dimensions | 12.2 in x 4.6 in x 12.9 in (311 mm x 117 mm x 327 mm) (LxHxW) | ||||
| Legal for Trade | Not Applicable | ||||
| Tare Range | To capacity by subtraction | ||||
| Working Environment | 14°F – 104°F, 85%RH, non-condensing (-10°C – 40°C, 85%RH, non-condensing) | ||||
| Platform Construction | ABS with Stainless Steel Inset | ||||
| Net Weight | 8.6 lb (3.9 kg) | ||||
| Second Scale Input | Not Applicable | ||||
| Protection Rating | Not Applicable | ||||
| In-Use Cover | Available as an Accessory | ||||
| Transportation Case | Not applicable | ||||
| Communication | RS232 (Included) | ||||
| Power | AC Power (Included); Rechargeable Battery (Included) | ||||
| Units of Measurement | Gram; Kilogram; Pound; Ounce; Pound:Ounce | ||||
| Display | 3-window backlight LCD + 3 LED | ||||
| Counting Resolution | 1:600,000 internal resolution | ||||
| Repeatability, typical | 0.1 g | 0.2 g | 0.4 g | 1 g | 2 g |
| Linearity ± | 0.1 g | 0.2 g | 0.4 g | 1 g | 2 g |
| Width (Shipping) | 397 mm | ||||
| Height (Shipping) | 195 mm | ||||
| Length (Shipping) | 442 mm | ||||
| Gross Weight (Shipping) | 5.45 kg | ||||
ACCESSORIES
|
Item Number 80500525 Description Cable RS232 IBM 9P Male-to-Female |
|
|
Item Number 30045641 Description Printer, Impact, SF40A |
|
|
Item Number 30037450 Description Hook R21 RC21 RC31 RC41 V71 |
|
|
Item Number 30037451 Description In-Use-Cover, R21 RC21 R31 RC31 |
|
|
Item Number 30037452 Description Pan SST R21 RC21 R31 RC31 R41 RC41 V71 |
